Resolution
|
300 dpi (12 dots/mm)
|
|
Print Method
|
Direct thermal/Thermal transfer
|
|
Display
|
Color LCD touchscreen with buttons
|
|
Hardwire Connectivity
|
Ethernet; GPIO; Parallel port; Serial RS-232; USB; USB Host
|
|
Wireless Connectivity
|
Bluetooth
|
|
Enterprise Printer Management
|
TSC Console
|
|
Type
|
Industrial
|
|
Max. Print Speed
|
4 ips (102 mm/s)
|
|
Max. Print Width
|
8.64″ (219.5 mm)
|
|
Max. Print Length
|
200″ (5,080 mm)
|
|
RAM
|
256 MB SDRAM
|
|
Flash
|
512 MB
|
|
Expandable Flash
|
SD memory card reader; up to 32 GB
|
Media Specification
| Specification | Details |
|---|---|
|
Internal Label Capacity
|
8.2“ (208.3 mm) OD
|
|
Max. Ribbon Length
|
600M
|
|
Ribbon Width
|
4.3“ – 10“ (110 mm – 254 mm)
|
|
Media Core Diameter
|
3″ (76.2 mm)
|
|
Min. Label Length
|
1″ (25.4 mm)
|
|
Construction
|
Die-cast chassis/Sheet metal structure with clear media view window
|
|
Programming Languages
|
TSPL-EZD
|
|
Max. Media Width
|
9.5″ (241.3 mm)
|
|
Media Type
|
Continuous, die-cut, fan-fold, tag, notched, black mark, perforated (outside wound)
|
